5* Multifocus Offset Professional Antenna BIG BISAT for up to 8 LNBs, including 4 LNB mounts with a reflector size of 91x71cm and up to 36 dB gain per LNB
– Compo multi-feed support
– Easy installation with one screw/hinge
– Aluminum feed legs
The antenna reflector is made of special plastic with glass fiber reinforcement, making it resistant to climatic conditions such as UV, moisture, ozone, oxidation, pollution, and corrosion.
The DRP material also withstands extreme temperatures from -50°C to 150°C.
Technical data:
LNB mounts: 4 LNBs incl.
Ø LNB mounts: 40 mm
Width x height: 91 cm / 70 cm
Frequency range: 10.7 – 12.75 GHz
Multi-beam capability: +/- 20° orbital (40° total)
Gain (dB): +/- 20° 36 dB
-3dB beam width 2.3°
G/T (12.5 GHz) 16 dBK
Tilt: 0° to 90°
For mast diameters: 40 to 60 mm
Weight: 9 kg
Color: anthracite
Alignment software (online): http://pointage.visiosat.com/Default.aspx
Quicksat app (mobile): https://play.google.com/store/apps/details?id=com.gmixon.quicksat
